Laser Tube Cutting
Engineering-driven tube laser fabrication that reduces build time while improving fit, finish, and consistency.
Request a QuoteTube Laser Engineering Features
Custom Laser offers engineering and implementation of several tube laser features to make fabrication easier, more accurate, and more efficient. Slot and tab construction, self-locating joints, single-piece construction, and part etching for identification are just a few ways tube laser technology can greatly reduce fabrication costs and provide a more accurate finished product.
Tube Cutting Details
- Max Laser Power
- 4,000 watts
- Max Tube Diameter
- 10.00″
- Min Tube Diameter
- 0.625″
- Max Stock Length
- 30 ft
- Max Finished Part Length
- 235.00″
- Max Weight Per Foot
- 25.2 lb
- True Bevel Cutting
- Up to 45°
Materials Supported
- Carbon steel up to 3/8″ wall thickness
- Stainless steel up to 1/4″ wall thickness
- Aluminum up to 1/4″ wall thickness
- Angle up to 4″ × 4″
- Channel up to C4
Equipment List
Trumpf 7000 CO₂ Tube Laser
(3,600 watt)
Trumpf 7000 Fiber Tube Laser
(4,000 watt)
